Specifications
Product Number | VPSFT-00802A |
Thread Size | 10-24 |
Length | 5/16" |
Threading | Fully Threaded |
Flat Head Profile | Standard |
Head Diameter | 0.411" |
Head Height | 0.127" |
Countersink Angle | 82° |
Drive Style | Hex |
Drive Size | 1/8" |
Material | 18-8 Stainless Steel |
Finish | Passivated |
Hardness | Rockwell B55 |
Tensile Strength | 70,000 psi |
Screw Size Decimal Equivalent | 0.190" |
Thread Type | UNC |
Thread Spacing | Coarse |
Thread Fit | Class 3A |
Thread Direction | Right Hand |
Head Type | Flat |
System of Measurement | Inch |
Specifications Met | ASME B18.3 |
RoHS | RoHS 3 (2015/863/EU) Compliant |
REACH | REACH (EC 1907/2006) (01/16/2020, 205 SVHC) Compliant |
