Hexagonal Head Concrete Screw 410 Stainless Steel 1/4-20 * 1-1/4" [Philips Drive]

Hexagonal Head Concrete Screw 410 Stainless Steel 1/4-20 * 1-1/4" [Philips Drive]

3.40 $ CAD
3.40 $ CAD
Sale Sold out
Shipping calculated at checkout.
Quantity
Download

Price may change with quantity see chart under PROMOTIONS


These 410 stainless steel screws are more corrosion resistant than ultra-corrosion-resistant coated steelscrews. They'realso known asTapcons. All have a hex head for a secure grip with awrench. Drive into a hole with a hammer drill or socketwrench, or use a specialized tool set(soldseparately). Pull-out strength and shear strength values are25%of the ultimatevalues.

View full details

Specifications
Product Number VCHS4-01012
Material 410 Stainless Steel
Diameter 1/4"
Length 1-1/4"
Screw Size 1/4"
Screw Size Decimal Equivalent 0.25"
Drill Bit Size 3/16"
Drill Bit Decimal Size Equivalent 0.1875"
Thread Length 1"
Min. Install. Depth 1"

Head
Width 11/32"
Height 0.18"
Flange Diameter 0.414"

Strength, lbs.
Pull-Out 190
Shear 225
Tested In 3, 000 psi Concrete
Drive Style External Hex
Head Type Hex
Hex Head Profile Standard
Thread Direction Right Hand
Tip Type Diamond Point
For Use In Block, Brick, Concrete
Removable Removable
Anchor Type Tapping Screw
System of Measurement Inch
RoHS RoHS 3 (2015/863/EU) Compliant
REACH REACH (EC 1907/2006) (01/16/2020, 205 SVHC) Compliant
