Oval Head Drilling Screw Stainless Steel #6 * 1/2" [Philips Drive]

Oval Head Drilling Screw Stainless Steel #6 * 1/2" [Philips Drive]

0.27 $ CAD
0.27 $ CAD
Sale Sold out
Shipping calculated at checkout.
Quantity
Download

Price may change with quantity see chart under PROMOTIONS


A decorative rounded top provides a finished appearance. These screws are beveled under the head for use in countersunk holes. They save you time and effort by drilling their own holes and fastening in a single operation. Made from steel, they have a 304 stainless steel to resist corrosion in wet environments. Length is measured from the top of the head.

View full details

Specifications
Product Number VTSO-06005
Material 304 Stainless Steel
Screw Size No. 6
Screw Size Decimal Equivalent 0.138"
Length 1/2"

Drill Tip
Type No. 2
Length 9/64"
Maximum Drilling Thickness 0.09"

Head
Diameter 0.279"
Height 0.128"
Drive Size No. 2
Drive Style Phillips
Approximate Threads per Inch 20
Thread Direction Right Hand
Threading Fully Threaded
Tapping Method Thread Forming
Tapping Screw Type BSD
Head Type Oval
Oval Head Profile Standard
Oval Top Height 0.045"
Countersink Angle 82°
Tip Type Drilling
Shank Cross Section Round
System of Measurement Inch
For Use In Steel, Sheet Metal
RoHS RoHS 3 (2015/863/EU) Compliant
REACH Not Compliant
DFARS Specialty Metals COTS-Exempt
